 TECHNICAL SPECIFICATION

Item

 Description

Specification/Technical Data

1

Manufacturer

ANT Engineering Ltd.

2

Type of panel

T-04S

3

Standard

IEC 60439-1, DIN EN 60439-1 (VDE 0660 Part 500)

4

Rated voltage (Ue)

415 V

5

Rated insulation voltage (Ui)

690 V

6

Impulse withstand voltage (Uimp)

6 KV

7

Rated short-time withstand current

50 kA/1s

8

Construction

Assembly

Type-Test Assembly (TTA) or Partial Type Test Assembly (PTTA)

Functional separation

Form 3b

Type of panel

Indoor type, floor mounting or wall mounted, front access

Dimensions

Height: 2200, 2600 ( with busbar top unit )

Width: 600, 800, 1000, 1200 mm

Depth: 600, 800, 1000, 1200 mm

Protection rating

IP 30 to IP 42 for indoor type; IP 54 for outdoor

Material

Electro-galvanized sheet steel

Thickness

2.0 mm

Finishing

powder coated, wet-paint

9

Bus-bar (3-pole and 4-pole)

Standard

IEC 60439-2

Rated currents (In)

Up to 6300A

Rated short-time withstand

Up to 65KA/ 1s

Arrangement

Main horizontal busbar: full length

Vertical busbar: full length

Bus-bar material

Copper Purity 99.9%

Bus-bar tinned

Yes

Bus-bar Size

PTTA

Bus-bar tap-off to functional unit
